The Smallest and powerful IR Laser Illuminator

Beamshot Night Stalker X-Zoom 1

The Smallest IR Laser Illuminator

Despite its remarkably small dimensions, the Smallest IR Laser Illuminator delivers outstanding performance. It utilizes advanced IR VCSEL laser diode technology with an adjustable beam size function, offering a range from 6.5 to 18 degrees. This feature ensures maximum illumination for various applications, including Night Vision Devices, Scopes, and IR Cameras, both for short-range and long-range use.

Features:

1. Measuring at just Ø21 x L102 mm (Ø0.82 x 4.02 inches) and weight approximately 44±10 g (1.55±0.35 oz), the Smallest IR Laser Illuminator stands out as a highly portable and light weight device. It can be easily carried as an IR Torch or mounted onto weapons to enhance the performance of NVDs, digital scopes, or cameras. The Smallest IR Laser Illuminator is perfect for a wide range of applications, including tactical scenarios, self-defense purposes, and hunting endeavors.

2. The Patented Switch includes a LED indicator for efficient battery management. When the laser is activated, the LED glows red, serving as a clear visual indicator of its operation. This feature prevents unnecessary battery drainage by providing a convenient way to identify laser usage.

3. The IR Laser Illuminator is designed to minimize front-facing red glow, reducing visibility and maintaining stealth in critical situations.

4. When adjusting the beam to a narrow divergence of 6.5 degrees, the IR Laser Illuminator can reach distances of around 200 meters. By narrowing the beam divergence, the illuminator concentrates the laser energy into a tighter and more focused beam, resulting in enhanced visibility and extended reach at longer distances.

5. When adjusting the beam to its widest divergence of 18 degrees, the IR Laser Illuminator can effectively spread light over a larger area for short-distance applications. The wider beam divergence enables broader coverage, illuminating a larger frontal area at shorter distances.

6. This illuminator utilizes an Eye-Safe Class I IR VCSEL laser diode, ensuring that it meets strict safety standards and its adjustable beam divergence function allows you to customize the beam angle from 6.5° to 18°, enabling you to identify targets in both narrow and wide areas within your shooting range.

• Dimensions:

Ø0.82" x 4.55" / Ø21 x 115.5(L) mm

• Weight:

44 g ± 10 g / 1.55 oz. ± 0.35 oz.

• Construction:

Aerospace-grade Aluminum

• Power Supply / Battery Life:

1 x CR123A / 2 hrs.

• Laser Type:

IR VCSEL Laser

• Wavelength:

830~860 nm

• Output Power:

Class I eye safe, more than 100mW, CW mode

• Beam Divergence:

Adjustable 6.5° ~ 18°
